| Size | Bending Radius |
| 1/4” 6MM ID 12MM OD Clear reinforced PVC Food Quality Hose 30M | 50MM / 1.97” |
| 5/16” 8MM ID 14MM OD Clear reinforced PVC Food Quality Hose 30M | 65MM / 2.56” |
| 3/8” 10MM ID 15MM OD Clear reinforced PVC Food Quality Hose 30M | 80MM / 3.15” |
| 1/2” 12.5MM ID 19MM OD Clear reinforced PVC Food Quality Hose 30M | 95MM / 3.74” |
| 5/8” 16MM ID 23MM OD Clear reinforced PVC Food Quality Hose 30M | 130MM / 5.12” |
| 3/4 “ 19MM ID 26MM OD Clear reinforced PVC Food Quality Hose 30M | 155MM / 6.10” |
| 1” 25MM ID 33MM OD Clear reinforced PVC Food Quality Hose 30M | 200MM / 27.87” |
| 1 1/4” 32MM ID 42MM OD Clear reinforced PVC Food Quality Hose 30M | 255MM / 10.04” |
| 1 1/2” 38MM ID 48MM OD Clear reinforced PVC Food Quality Hose 30M | 305MM / 12.01” |
| 2” 50MM ID 63MM OD Clear reinforced PVC Food Quality Hose 30M | 400MM / 15.75” |
KEY FEATURES:
- An effective, functional choice for a diverse range of applications especially when the budget is a factor.
- Glass clear clarity for excellent visibility.
- Excellent resistance to abrasion.
- Manufactured from cadmium and silicone-free materials using a special low toxic, odourless PVC formulation that can reduce the taint of drinking water.
- Suitable for food, water, chemicals, gas, fuel and oils.
- EC compliant for food contact applications.
- RoHS compliant.
- Highly resistant to a wide range of acids and alkalis.
- Service temperature = -15°C to + 60°C.
- Specially selected high tensile polyester fibres used at the optimum braid angle of 54° 44’(54.73°) creates an effective and balanced pressure hose.
- Manufactured in accordance with BS EN ISO 6224.
- 3:1 safety factor @ 23°c.
SIZES:
- Available in 30m coils
- 6.3mm-50mm ID
COLOURS:
- Clear
- Custom sizes and colours available on request subject to minimum order quantity
APPLICATION EXAMPLES:
- A wide variety of shop floor airline applications.
- Popular for pharmaceutical / scientific applications for the transfer of chemicals.
- For the transfer of food substances and liquids.
