Dimensions
Model |
Length |
Width |
Height |
Tube Diameter |
Wire/Connector |
500 GPH |
5 1/2” |
3 1/4” |
4” |
3/4” |
29” Wire |
750 GPH |
5 1/2” |
3 1/4” |
4” |
3/4” |
29” Wire |
1100 GPH |
5 1/2” |
3 1/4” |
4” |
1 1/8” |
29” Wire |
Specifications (Motor Running)
GPH Output @ Design Voltage 13.6 VDC |
||||||||
Model No |
Rated Voltage |
Design Voltage |
Amp Draw |
0 ft |
3.3 ft |
6.7 ft |
Max Head |
Fuse Size |
500 GPH |
12 |
13.6 |
1.5 |
500 |
350 |
200 |
9 ft |
3-amp |
750 GPH |
12 |
13.6 |
2.8 |
750 |
625 |
450 |
16 ft |
5-amp |
750 GPH |
24 |
27.2 |
1.5 |
750 |
625 |
450 |
16 ft |
2-amp |
1100 GPH |
12 |
13.6 |
4 |
1100 |
973 |
750 |
11 ft |
6-amp |
GPH Output @ Nominal Voltage 12.0 VDC |
||||||||
Model No |
Rated Voltage |
Design Voltage |
Amp Draw |
0 ft |
3.3 ft |
6.7 ft |
Max Head |
Fuse Size |
500 GPH |
12 |
13.6 |
1.2 |
450 |
300 |
190 |
8 ft |
3-amp |
750 GPH |
12 |
13.6 |
2.5 |
660 |
480 |
345 |
12 ft |
5-amp |
750 GPH |
24 |
27.2 |
1.2 |
660 |
480 |
345 |
12 ft |
2-amp |
1100 GPH |
12 |
13.6 |
3.4 |
1070 |
820 |
615 |
9 ft |
6-amp |
