Roy - RY6 4000ACD Windlass 4000W 230/400V 16mm D
SKU
FSRY40TRD016A00
High-capacity AC vertical windlass for 16mm chain. 4000W dual-direction system
£6,072.44
RRP
Ex. VAT
Vertical windlasses
Stainless steel AISI 316 base, drum and gypsy cover
With and without drum
Integrated sensor and magnet for chain counter
Safety mechanical band brake
IP67 watertight motor (HYDRO)
Anodized aluminium gearbox
| Standard Version | RY6 AC 4000 / 4000 D |
|---|---|
| Motor Power | 4000 W |
| Motor Supply Voltage | 230 / 400 V AC (1) |
| Maximum Pull | 4000 kg / 8818 lb |
| Maximum Working Load | 1500 kg / 3307 lb |
| Maximum Chain Speed (2) | 20 m/min / 65.6 ft/min |
| Weight – Duke (without drum) | 88 kg / 194 lb |
| Weight – Duke D (with drum) | 93 kg / 205 lb |
|
(1) Available on request in 230 V single-phase version (2) Measurements taken with a gypsy for a 14 mm chain |
|
Boat size chart
| Manufacturer SKU | Model | Motor Power | Boat Length (m) | Boat Length (ft) |
|---|---|---|---|---|
| FSRY30TRD014A00 | ROY | 3000 W DC | 18 – 26 m | 60 – 85 ft |
| FSRY35TRD014A00 | ROY | 3500 W DC | 22 – 29 m | 75 – 95 ft |
| FSRY40TRD016A00 | ROY | 4000 W AC | 18 – 29 m | 60 – 95 ft |
| FSRY55TRD018A00 | ROY | 5500 W AC | 22 – 32 m | 75 – 105 ft |
| FSRYHYDRO016A00 | ROY | HYDRO | 20 – 32 m | 60 – 105 ft |
| The indication may vary according to the boat type and the anchor-rode type. | ||||
