100ah |
12v |
24v |
36v |
App + Bluetooth |
Yes |
Yes |
Yes |
Battery Type |
LiFePO4 |
LiFePO4 |
LiFePO4 |
Casing Protection |
Yes |
Yes |
Yes |
Cycles |
2000 |
2000 |
2000 |
DOD |
100% |
100% |
100% |
Full Charge Voltage |
14.6V |
29.2V |
43.8V |
In Series |
no |
no |
no |
Max Charge Current |
60AMP |
60AMP |
60AMP |
Max Continuous Discharge Current |
120AMP |
100AMP |
120AMP |
Nominal Voltage |
12.8V |
25.6V |
38.4V |
Parallel |
2 |
2 |
2 |
Size (LxWxH) with package (UN casing size) |
530*320*350mm |
620*380*290mm |
620*380*290mm |
Size (LxWxH) without package standard charge |
325*170*235mm 10AMP |
520*270*230mm 7AMP |
520*270*230mm 8AMP |
Usable WATTS |
1280WH |
2560WH |
3840WH |
Weight with package |
+/-12KGS |
+/-24KGS |
+/-32KGS |
Weight without package |
+/-10.5kgs |
+/-22kgs |
+/-29kgs |
