- SwitchFire Sonar: Take command of how your sonar returns appear. With two display modes, you can add or remove detail, account for water depth, temperature and turbulence, even watch lure presentations - all at the push of a button.
- Dual Beam PLUS Sonar: Two beams combine for great detail and a generous coverage area, helping you identify fish, structure and contours. Use the narrow beam for high-accuracy returns of fish, structure, detail and the bottom profile. Opt for the wide beam when you want a larger search area. You can view the beams separately, side-by-side or blended together for the complete picture. Your coverage area will be equal to your depth.
- 1-Year Limited Warranty
Item Number | 410190-1 |
Series | HELIX |
Display Size - Diagonal | 5" |
Display Pixel Matrix | 800H x 480V |
Sonar-Standard | DualBeam PLUS |
Sonar-Coverage | 20° & 60° @ -10dB |
Sonar-Frequencies Supported | 83/200 kHz |
Depth-Sonar | 1,500 ft (standard transducer) |
Interface | Keypad Control |
Memory Card Slot | None |
Compatible With | AIS, AutoPilot |
Power Draw | 615 mA |
Power Input | 10.8-20 VDC |
Power Output Peak-to-Peak | 4000 Watts |
Power Output RMS | 500 Watts |
Screen SnapShot | Not Supported |
Sonar Recording | Not Supported |
Mount-Standard | Gimbal |
Mount-Standard Size | 7.55" W x 4.64" H x 3.3" D |
Mount-Optional Size | 7.55" W x 4.28" H x 1.13" D |
Transducer Mount Location | Transom |
GPS Chartplotting | Not Supported |
GPS Trackplotting | Not Supported |
LakeMaster Compatibility | No |
Coast Master Compatibility | No |
Navionics Gold/HotMaps Compatibility | No |
Navionics Platinum + Compatibility | No |
Platinum Compatibility | No |
Heading Sensor GPS Compatibility | No |
Upgradable Software | Yes |
View Preset Keys | No |
X-Press Menu System | Yes |
Custom Digital Readout | Yes |
Custom View Selections | Yes |
Display Colors Grayscale | 16-Bit |
Display Size | 5" - 7" |
Speed | Optional |
Temperature | Built-In |
Temperature Alarm | Yes |
Temperature Graph | No |
Transducer Included | XNT 9 20 T |
HDMI Compatible | No |
MEGA Live Compatibility | No |
