CALIBRATED Hot Dip GALV Chain 8mm 60m

Waveline
SKU
WL-0814-0708-60

The majority of windlasses require chains in accordance with either DIN 766 or ISO 4565. DIN 766. this standard is for calibrated and tested chains using Grade 30 material (per Waveline specifications). ISO 4565, EN 24565 or BS 7160 are all the same standard which covers anchor chains for small crafts. Producing to these standards ensures the chain is a standard fit and suitable for most windlass on the market today including Lofrans®, Lewmar®, Quick® etc.

Calibrated chain, suitable for use with a windlass. Chain Grade: 30. Packaged in a metal drum.

£516.62
RRP Ex. VAT

Part No

Diameter

Length

P x W (mm)

Breaking Load

WL-0814-0706

6mm

30m

18.5 x 20.2

1400kg

WL-0814-0706-60

6mm

60m

18.5 x 20.2

1400kg

WL-0814-0708

8mm

30m

24 x 27.2

2500kg

WL-0814-0708-60

8mm

60m

24 x 27.2

2500kg

WL-0814-0710

10mm

30m

28 x 34

3400kg

WL-0814-0710-60

10mm

60m

28 x 34

3400kg

WL-0814-0710-100

10mm

100m

28 x 34

3400kg

WL-0815-0712

12mm

30m

34 x 40.8

4480kg

WL-0814-0712-150

12mm

150m

34 x 40.8

4480kg



PART NO. A B C SWL, KN (TONS) UTS, KN (TONS) WEIGHT (KG PER M) STANDARD
WL-0814-0706 6 18.5 8 4 (0.4) 16 (1.6) 0.81 DIN 766 AND ISO4565
WL-0814-0708 8 24 12  7.5 (0.75) 30 (3.0) 1.42 DIN 766 AND ISO4565
WL-0814-0710 10 28 14  12.5 (1.25) 50 (5.0) 2.21 DIN 766
WL-0814-0712  12 36  18 17.5 (1.75) 70 (7.0)  3.25 DIN 766 AND ISO4565
