Load Bearing Collar ABYC H-27 Rated - Medium - Black

Tru Design
SKU
TRU90857
✕
Size (Cm) XS S M L XL XXL
Height 155-160 160-165 170-175 180-185 185-190 190-195
Chest 82-86 87-91 97-101 107-111 112-116 117-121
Waist 66-70 71-75 81-90 91-95 96-100 101-105

TruDesign Load Bearing Collars are designed for use with TruDesign Skin Fittings and Ball Valves. With the Collar in place, the Skin Fitting-Ball Valve-Hose Tail assembly will withstand a 500lb (227 kg) static force applied to the Hose Tail end of the assembly, for a minimum of 30 seconds – complying with North American ABYC H-27 standards.

£14.43
RRP Ex. VAT
Where to buy

Note: TruDesign 1 1/4", 1 1/2" 2" Skin Fittings meet the requirements of H-27 500Lb standard (i.e. without a Large Collar installed). Adding a Large Collar to assemblies of this size increases the overall strength and protects the vulnerable exposed section of thread on the Skin Fitting.



  • American ABYC H-27 – 500Lb static load test - TRUDESIGN Skin Fittings and Ball Valves meet the American ABYC H-27 – 500Lb static load test; Seacocks, Thru-Hull Fittings, and Drain Plugs – independently verified by IMANNA Laboratory Inc.
  • 1” Thru Hull, Ball Valve and Tail assembly complies with the ABYC 500Lb load test only when used with the TruDesign ABYC collar
  • ½” and ¾” do not comply with the ABYC load test standard
  • Compact footprint
  • No additional bolts or fasteners through or on to the hull
  • Ability to retrofit to existing TruDesign assemblies
  • Shrouded protection
  • Fool-proof assembly - if not snug when tightened the Skin Fitting's length will need shortening. See info sheet
  • Compatible - Works with many hull types - aluminium, steel, wood or GRP hulls.
  • Corrosion Free - Long life with no decreased performance due to corrosion or electrolysis.
  • Strong and Lightweight - Manufactured from a glass reinforced nylon composite - High strength without the weight.
